Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
174
Bit
Name
R/W
Reset Value
Description
 Fan speed (RPM) = Reg_value * 100
EX: register value : 80
The RPM value is 80*100 = 8000
5.12.8.20. Offset 0x25 Rear Fan4 Module Speed (Read Only)
Bit
Name
R/W
Reset Value
Description
7:0
Rear_Fan4_Tach
R
0
0: Fan failed
1 ~ 255: the number of fan rotations in 600ms
 Fan speed (RPM) = Reg_value * 100
EX: register value : 80
The RPM value is 80*100 = 8000
5.12.8.21. Offset 0x26 Rear Fan5 Module Speed (Read Only)
Bit
Name
R/W
Reset Value
Description
7:0
Rear_Fan5_Tach
R
0
0: Fan failed
1 ~ 255: the number of fan rotations in 600ms
 Fan speed (RPM) = Reg_value * 100
EX: register value : 80
The RPM value is 80*100 = 8000
5.12.8.22. Offset 0x27 Rear Fan6 Module Speed (Read Only)
Bit
Name
R/W
Reset Value
Description
7:0
Rear_Fan6_Tach
R
0
0: Fan failed
1 ~ 255: the number of fan rotations in 600ms
 Fan speed (RPM) = Reg_value * 100
EX: register value : 80
The RPM value is 80*100 = 8000
5.12.8.23. Offset 0x30 Fan Module Power enable (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
reserve
NA
NA
5
Fan_Power6
R/W
1
1: Enable the fan Power
0: Disable the fan power
4
Fan_Power 5
R/W
1
1: Enable the fan Power
0: Disable the fan power
3
Fan_Power 4
R/W
1
1: Enable the fan Power
0: Disable the fan power
2
Fan_Power 3
R/W
1
1: Enable the fan Power
0: Disable the fan power
1
Fan_Power 2
R/W
1
1: Enable the fan Power
0: Disable the fan power
0
Fan_Power 1
R/W
1
1: Enable the fan Power
0: Disable the fan power
5.12.8.24. Offset 0x31 Watchdog timer (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:0
Watchdog timer
R/W
0x06
A countdown timer with 1 second resolution.
Default value is 6 sec.
5.12.8.25. Offset 0x32 Watchdog Maximum PWM value (Read& Write)
TBD.
