Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
175
When system hang and watchdog (WD=0) , Fan should be max speed.
I want to remove this resgister.
Bit
Name
R/W
Reset Value
Description
7:4
reserve
NA
NA
3:0
Watchdog Maximum
PWM value
R/W
1111
5.12.8.26. Offset 0x33 Watchdog disable (Read& Write)
Pls set the value at 0 by default at sample run stage.
Bit
Name
R/W
Reset Value
Description
7:1
reserve
NA
NA
0
Watchdog disable
R/W
1
1: Enable the watchdog timer
0: Disable the watchdog timer
5.12.8.27. Offset 0x42 Fan LED (Read& Write)
Bit
Name
R/W
Reset Value
Description
7
LED_Debug_mode
R/W
0
1:LED debug mode on
0:LED debug mode off
6:0
Reserve
N/A
N/A
5.12.8.28. Offset 0x43 Fan1 Vendor ID (Read Only)
Bit
Name
R/W
Reset Value
Description
7:3
Reserve
NA
NA
2:0
Fan1_Vendor ID
R
000
Fan Vendor control bit
Fan Vendor control bit
PIN[9, 10,11]
bit [9, 10,11]=100 -->AVC
bit [9, 10,11]=101 -->Sunon
bit [9, 10,11]=110 -->Nidec
5.12.8.29. Offset 0x44 Fan2 Vendor ID (Read Only)
Bit
Name
R/W
Reset Value
Description
7:3
Reserve
NA
NA
2:0
Fan2_Vendor ID
R
000
Fan Vendor control bit
Fan Vendor control bit
PIN[9, 10,11]
bit [9, 10,11]=100 -->AVC
bit [9, 10,11]=101 -->Sunon
bit [9, 10,11]=110 -->Nidec
5.12.8.30. Offset 0x45 Fan3 Vendor ID (Read Only)
Bit
Name
R/W
Reset Value
Description
7:3
Reserve
NA
NA
2:0
Fan3_Vendor ID
R
000
Fan Vendor control bit
Fan Vendor control bit
PIN[9, 10,11]
bit [9, 10,11]=100 -->AVC
bit [9, 10,11]=101 -->Sunon
bit [9, 10,11]=110 -->Nidec
