Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
95
5
Reset* PCA9548_I2C_1; 0x75
(PCA9548_15_RESET_N)
R/W
1
1: PCA9548 is placed in normal operation state. (Default)
0: PCA9548 is placed in reset state.
4
Reset* PCA9548_I2C_1; 0x74
(PCA9548_14_RESET_N)
R/W
1
1: PCA9548 is placed in normal operation state. (Default)
0: PCA9548 is placed in reset state.
3
Reset* PCA9548_I2C_1; 0x73
(PCA9548_13_RESET_N)
R/W
1
1: PCA9548 is placed in normal operation state. (Default)
0: PCA9548 is placed in reset state.
2
Reset* PCA9548_I2C_1; 0x72
(PCA9548_12_RESET_N)
R/W
1
1: PCA9548 is placed in normal operation state. (Default)
0: PCA9548 is placed in reset state.
1
Reset* PCA9548_I2C_1; 0x71
(PCA9548_11_RESET_N)
R/W
1
1: PCA9548 is placed in normal operation state. (Default)
0: PCA9548 is placed in reset state.
0
Reset* PCA9548_I2C_1; 0x70
(PCA9548_10_RESET_N)
R/W
1
1: PCA9548 is placed in normal operation state. (Default)
0: PCA9548 is placed in reset state.
5.12.2.8. Offset 0x07 System Reset-4 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7
Reset* SHUTDOWN_WAKE
(shutdown_wake)
R/W
1
1: Enable Main board’s power (Default)
0: Main board go to shutdown mode
6
Reset* Manu_RST
(MANU_RST)
R/W
1
1: Manu_RST is placed in normal operation state. (Default)
0: Manu_RST is placed in reset state.
5
Reset* BCM56873
(MAC_RESET_N)
R/W
1
1: BCM56873 is placed in normal operation state. (Default)
0: BCM56873 is placed in reset state.
4
Reset* USB_RESET
(USB_RESET_N)
R/W
1
1: USB_RESETis placed in high. (Default)
0:USB_RESETis placed in Low.
3
Reset* MAC’s PCIE
(PCIE_PERST_L)
R/W
1
1: MAC’s PCIE is placed in high. (Default)
0:MAC’sPCIEis placed in Low.
2
Reset* CPLD2,3
(CPLD_RST)
R/W
1
1: CPLD2,3 is placed in normal operation state. (Default)
0:CPLD2,3 is placed in reset state
1
Reset* IDT8V89307
(IDT8V89307_RST)
R/W
1
1: IDT8V89307 is placed in normal operation state. (Default)
0:IDT8V89307 is placed in reset state.
0
Reset* MGMT PHY
(MGMT_PHY_RST_N)
R/W
1
1: MGMT-phy is placed in normal operation state. (Default)
0: MGMT-phy is placed in reset state.
5.12.2.9. Offset 0x08 System Reset-5 (Read Only)
Bit
Name
R/W
Reset Value
Description
7:4
Reserve
NA
NA
3
CPU_JTAG_RST
R
1
1: CPU_JTAG_RST is placed in normal operation state.
