Routing Protocol 3-206
RIP 3-224
General Settings Enables or disables RIP, sets the global RIP version and timer
values
3-225
Network Addresses Configures the network interfaces that will use RIP 3-227
Interface Settings Configures RIP parameters for each interface, including send
and receive versions, message loopback prevention, and
authentication
3-228
Statistics Displays general information on update time, route changes and
number of queries, as well as a list of statistics for known
interfaces and neighbors
3-231
OSPF 3-234
General Configuration Enables or disables OSPF; also configures the Router ID and
various other global settings
3-235
Area Configuration Specifies rules for importing routes into each area 3-238
Area Range Configuration Configures route summaries to advertise at an area boundary 3-241
Interface Configuration Shows area ID and designated router; also configures OSPF
protocol settings and authentication for each interface
3-243
Virtual Link Configuration Configures a virtual link through a transit area to the backbone 3-247
Network Area Address
Configuration
Defines OSPF areas and associated interfaces 3-249
Summary Address
Configuration
Aggregates routes learned from other protocols for advertising
into other autonomous systems
3-252
Redistribute Configuration Redistributes routes from one routing domain to another 3-253
NSSA Settings Configures settings for importing routes into or exporting routes
out of not-so-stubby areas
3-254
Link State Database
Information
Shows information about different OSPF Link State
Advertisements (LSAs) stored in this router’s database
3-256
Border Router Information Displays routing table entries for area border routers and
autonomous system boundary routers
3-258
Neighbor Information Displays information about neighboring routers on each
interface within an OSPF area
3-259
DVMRP 3-264
General Settings Configure global settings for prune and graft messages, and the
exchange of routing information
3-264
Interface Settings Enables/disables DVMRP per interface and sets the route metric 3-267
Neighbor Information Displays neighboring DVMRP routers 3-269
Routing Table Displays DVMRP routing information 3-270
