Specifications

A-3

Table A-5 EV1000 Monitor Technical Specifications

Input/Output

Touch Screen Resistive type

RS232 Serial Port Edwards proprietary protocol; Maximum data rate = 57.6 kilo baud

USB Port Three USB V1.1 compatible type A connectors on the monitor.

RJ-45 Ethernet Port Two

VGA Port One

Electrical

Voltage 24V, 1.8A max

Table A-6 EV1000 Pump-Unit Technical Specifications

Electrical

Voltage 100 to 240 Volts AC

50/60 Hz

Power Consumption 100 VA, maximum

Protection against electric shock Class I equipment

Main Page
