STP-iX457/iXU457 Series Turbomolecular Pump
MT-86E-001-F
Page 111
5
SERIAL COMMUNICATION PROTOCOL
Example:
TMS temperature: 0046
hex
= 70 ºC (158ºF)
Motor temperature: 0014C
hex
= 20 ºC (68ºF)
Motor current: 19
hex
= 2.5A
Measured rotational speed: 01C2
hex
= 450 Hz = 27,000 rpm
Control unit temperature : 0032
hex
= 50 °C
Parameter 1
ASCII
*1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1
HEX
Parameter 1 2
ASCII
*1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1
0 0 4 6
HEX
30 30 34 36
Parameter 3 4 5 6 7
ASCII 0 0 1 4
*1 *1
1 9
*1 *1 *1 *1 *1 *1
0 1 C 2
HEX 30 30 31 34 31 39 30 31 43 32
Parameter 8 9
ASCII
*1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1 *1
0 0 3 2
HEX 30 30 33 32
*1 System reservation
