Edwards STP-iX457 Series User Manual

STP-iX457/iXU457 Series Turbomolecular Pump
MT-86E-001-F
Page 14
TECHNICAL DATA
PAG
E
14
2
No. Item Description
1 Center of gravity
2 Control unit
3 Outlet port flange KF25
4 Screw hole for securing the
base
4-M10
Depth 18
5 Purge port KF10
Inlet
port flange
ISO100 ISO100F ISO160 ISO160F ICF152 ICF203 VG100 VG150
φA
130
165 180
225 152 203 182 235
φB
152
152 152
152 152 152 152 152
C 12 12 12 16 21 22 12 12
D
181
181 146
146 181 146 181 146
E 286 286 256 256 286 256 286 256
φF
-
145 -
200 130.2 181 160 210
G - 22.5
- 22.5 11.25 9 22.5 22.5
φH
-
9 -
11 8.4 8.4 12 12
I 197 197 167 167 197 167 197 167
J 207 207 177 177 207 177 207 177
Figure 8 - External appearance of STP-iX457C
H
(2)
(4)
