STP-iX457/iXU457 Series Turbomolecular Pump
MT-86E-001-F
Page 156
10
SERVICE, SPARES AND ACCESSORIES
10.4 Accessories
The following is a list of accessories that can be purchased by contacting Edwards.
Items Application purpose Remarks
Instruction Manual STP Pump Instruction Manual This manual
Supplied with STP pump
Connector for
“X1 DC POWER”
A connector for cable to connect to
"X1 DC POWER"
Model:
NJC–2410–PF
(Nanaboshi Electric Mfg.co.,Ltd)
NJC–24–CB
(Nanaboshi Electric Mfg.co.,Ltd)
* With cable bushing
Connector for
“X2 REMOTE”
A connector for cable to connect to
"X2 REMOTE"
High density D-sub 15 pin
Power supply unit
*1
(iPDF-240-24V)
DC power supply unit for
STP-iX457/iXU457 series
AC power cable
*1
Power supply AC cable for the
power supply unit iPD-240-24V
With one-side crimp-type terminal.
No shielded cable.
Standard cable length is 3m.
iPD-240 connection
cable
*1
Connection cable between STP
pump and power supply unit iPD-
240-24V
Shielded cable.
Standard cable length is 5m.
(max 20m)
STP-Link
*1
Windows application for operating or
monitoring the STP pump, or setting
various settings.
Dedicated communication cable is
included.
Standard cable length is 3m.
Air-cooling unit (U3-86)
*1
Air-cooling unit for the STP pump
and control unit, connecting by the
attached cable with X3 OPTION
No shielded cable.
Cable length is only 0.3m.
Vent valve
*1
Purge port ON/OFF controlled with
the attached cable which is
connected with X3 OPTION
No shielded cable.
Standard cable length is 0.28m
(max 2m).
*1
Optional accessory (Each accessory must be ordered separately)
To Next Page
