SAFETY FUNCTIONS
7.4 WARNING function setting
The WARNING functions can be set to Enable or Disable. Set to "ENABLE" when using the
WARNING function. Set to "DISABLE" to release each WARNING function after the WARNING is
detected.
A setting value of the "Pump Run Time Over" and "Pump Overload" are adjustable. The WARNING
detection can be released by setting the value larger than pump running hours after "Pump Run Time
Over" is detected. Also, the WARNING detection can be released by powering off the pump after
"Pump Overload" is detected.
See Table 38 and Table 39 for the default setting. The setting can be changed via serial
communication, the STP-Link (optional accessory) or the power supply unit iPD-240-24V (optional
accessory).
WARNING function Default setting User setting
User setting
change (threshold)
Second Damage Limit Enable Disable Disable
First Damage Limit Enable Enable Disable
Pump Run Time Over Disable Enable Enable
Pump Overload Disable Enable Enable
Imbalance Enable Enable Disable
Other Warning Enable Disable Disable
Table 38 - Default setting of WARNING function
WARNING function
Factory setting
(threshold)
Variable range
User setting
change (threshold)
Pump Run Time Over 0 hour
0 to 100,000
hours
It can be set in units of 100
hour. 0 is not counted.
Pump Overload
Motor
current
100.0 % 0 to 100.0 %
The ratio (%) to the rated
current value. Smaller
value has high possibility to
get "WARNING".
Rotational
speed
0.0 % 0 to 100.0 %
The rate (%) to the rated
speed value. Larger value
has high possibility to get
"WARNING".
Table 39 - Factory Setting and Variable Range
Note: Refer to Section 5, "Serial Communication Protocol", STP-Link, or the power supply unit
iPD-240-24V Instruction Manuals for the setting methods.
