Edwards STP-iX457 Series User Manual

STP-iX457/iXU457 Series Turbomolecular Pump
MT-86E-001-F
Page 119
5
SERIAL COMMUNICATION PROTOCOL
5.4.18 ReadCondition
Function: Reads the pump model and damage point.
Transmission frame:
*1
PC→SIM
Stx 0 0 1 ? { Etx LRC
SIM→PC
Ack
PC→SIM
*1
Ack
SIM→PC
Stx 0 0 1 Sp { Parameter 1 to 4 Etx LRC
*1 The HEX code of ASCII character ' { ' is "7B".
Parameter Item Data format Remarks
1 Pump model 160-bits hexadecimal
coded ASCII
2 [System reservation] 32-bits hexadecimal
coded ASCII
3 Damage point 16-bits hexadecimal
coded ASCII
4 [System reservation] 64-bits hexadecimal
coded ASCII
