STP-iX457/iXU457 Series Turbomolecular Pump
MT-86E-001-F
Page
62
4
OPERATION
START IN」(X2.pin01
Open
(
OFF
)
Close
(
ON
)
Type-A:
PROG IN (X2.pin11)
Open (OFF) STOP request START request
Close (ON)
STOP request
RESET request
Undefined
(Don’t use)
Figure 41 - X2 REMOTE Pin function matrix for input signal (Type-A PROG-IN)
START IN」(X2.pin01
Open
(
OFF
)
Close
(
ON
)
Type-B:
PROG IN (X2.pin11)
Open (OFF) STOP request START request
Close (ON)
STOP request
RESET request
START request
for 2nd SPEED
Figure 42 - X2 REMOTE Pin function matrix for input signal (Type-B PROG-IN)
4.8.2 Input operation port setting
Set the input operation port to the parallel port when operating the STP pump via the connector X2. The
input operation port can be changed by "Remote Operation Mode" setting.
The default setting of the Remote Operation Mode is "I/O Remote" (parallel port). It can be set via serial
communication, the STP-Link or (optional accessory) or the power supply unit iPD-240-24V (optional
accessory).
