STP-iX457/iXU457 Series Turbomolecular Pump
MT-86E-001-F
Page 130
6
STP-LINK AND DISPLAY UNIT
6.2 Power supply unit
The "power supply unit iPD-240-24V" operates the STP pump, confirms the pump status or sets
various settings, as well as the conventional "Display Unit". The power supply unit iPD-240-24V is
equipped with an LCD and flat panel switches.
See the Instruction Manual of the "Power supply unit iPD-240-24V" for the detailed specification and
operating methods.
STP-Link
BRAKE
ACCEL.
STOP
START
NORMAL FAILURE
POWER
UP
DOWN ENTER
SELECTRESET
65
98.4
132
122.5
Figure 62 - Power supply unit iPD-240-24V
