Section G - Ice and Water Dispenser
To replace Crusher Blades:
 1. RemoveAugerNuttogainaccesstoCrusher
Blades.EachbladeisseparatedbySpacer.
(SeeFigureG6)
 2. RemoveCrusherBladesandSpacersuntil
yougettoonethatneedsreplacement.
 3. Replaceassemblyinreverseorder.
Figure G6
Gaining Access
Toservicethecontrolboardyoumustremovethe
framearoundthedispenserhousingbypulling
straightoutatthetopcornerandworkingyourway
aroundtheframepullingitoutofthegroveinthe
door.(SeeFigure7)
Ice and Water Dispenser
Assembly
Feature Levels
Theiceandwaterdispenserhasoneactuatorsfor
bothwaterandice.(SeeFigure1)
Figure 1
Figure 2
1 2 3 4 5 6 7
Thefeaturelayoutusedontheiceandwaterside
bysideswillbeaSevenSelectorDispenser.
Seven Selection Dispenser: (See Figure
2)
1.  FastIce-Presstoincreaseiceproductionfor
aperiodof12hours
2.  FastFreeze-Presstodropfreezertempto
-6Fforaperiodof16hours.
3.  Water-Presstogetwateroutofdispenser
4.  Cubed-Presstogetcubedice.
5.  Crushed-Presstogetcrushedice.
6.  Light-Presstoturnonlightindispenser.
7.  Lock-Presstodisabledispenser.
(ChildLock)
Figure 3
