Electrolux E23CS75DSS0 - To Replace Motor; To Replace Water Fill Switch; To Replace Hold Switch; To Replace Ice Maker Control Arm Shutoff Switch

88
Section F - Ice Maker
ToReplaceMotorandSwitchMountingPlate
1. Removeicemakerfromfreezer.
2.  RemovefrontCover.
3.  Removetwoscrewsthatattachmounting
platetosupporthousing.
4.  Carefullyremovemountingplate,
disengagingendofsweeparmandnoting
relativepositionofsweeparmspring.
5.  Transfermotor,switches,cam,gear,and
waterlladjustingspringandarmto
replacementmountingplate.
6.  AttachnewmountingplatetoSsupport
housingwiththreescrews.
NOTE
Ensurethatthewiringharnessisproperly
positionedandthesweeparmisinplace.
7.  Checkwaterllcycleandadjustasrequired.
8. Replacefrontcover.
To Replace Motor (Figure F2)
1. Removeicemakerfromfreezer.
2.  Removefrontcover.
3.  Removetwoscrewsthatattachmounting
platetosupporthousing.
4.  Disconnecttwomotorleads.
5.  Removetwomotormountingscrews.
6.  Replacemotorinreverseorder.
To Replace Water Fill Switch (Figure F2)
1. Removeicemakerfromfreezer.
2.  RemovefrontCover.
3.  Removetwoscrewsthatattachmounting
platetosupporthousing.
4.  Disconnecttwowaterllswitchwireleads.
5.  Removetwoswitchmountingscrews.
6.  Removeswitch.
7.  Replaceswitchinreverseorder,ensuring
thatswitchinsulatorisinplace.
8.  Checkwaterllcycleandadjustasrequired.
To Replace Hold Switch (Figure F2)
1. Removeicemakerformfreezer.
2.  Removefrontcover.
3.  Removetwoscrewsthatattachmounting
platetosupporthousing.
4.  Disconnectsixholdswitchwireleads.
5.  Removetwoholdswitchmountingscrews.
6.  Removeholdswitch.
7.  Replaceinreverseorder.
To Replace Ice Maker Control Arm Shut-OFF
Switch
1. Removeicemakerformfreezer.
2.  RemovefrontCover.
3.  Removetwoscrewsthatattachmounting
platetosupporthousing.
4.  Disconnectthreeicemakercontrolarm
shut-offswitchwireleads.
5.  Raiseicemakercontrolarmlever.
6.  Removetwoicemakercontrolarmshut-off
switchmountingscrews.
7.  Removeswitch.
8.  Replaceswitchinreverseorder.
To Replace Ice Maker Thermostat (Figure F6)
1. RemoveIceMakerformFreezer.
2.  RemovefrontCover.
3.  Removetwoscrewsthatattachmounting
platetosupporthousingandremoveplate.
4.  Disconnecttwothermostatwireleadsand
removethermostat.
5.  Removetwoscrewsthatattachmoldto
supportHousingseperatehousingandice
mold.
6.  Removethermostat.
7.  Applythermalmasticsealertosensing
surfaceofreplacementthermostatto
ensureapositivebondtomold.
8.  Replacethermostatinreverseorder.
To Replace Thermal Cut-Out (TCO)
1. RemoveIcemakerformfreezer.
2.  RemovefrontCover.
3.  Removetwoscrewsthatattachmounting
platetosupporthousing.
4.  Pullcableassemblyfreefromsupport
housing.Itwillslideouteasily.
5.  LoosenscrewsecuringclamptoTCO.TCO
shouldcomefreeaftertensionfromclampis
released.
