Section F - Ice Maker
EXAMPLE:Anicemakeristest-cycledand
thewaterllsampleis93cubiccentimeters.
Subtracting80ccfrom93,theadjustmentneeded
is13cc.Sinceoneturnoftheadjustingscrew
changesthell18cc,¾ofaturnclockwisewould
reducethellabout13cc,thedesiredamount.
(Thisexampleisformanualmodelsonly.)
Parts Replacement
Disconnectelectricalsupplytorefrigerator.
To Replace Front Cover (Figure F4)
1. Removeicemakerfromfreezer.
2.  Ensurethaticemakerisatroom
temperaturebeforeremovingCover.
3.  Removescrewatthetopofthecoverandtip
itoutuntilthetabatthebottomcomesoutof
thehousing.
5.  Installinreverseorder.
Figure F 4
To Replace Fill Trough (Figure F6)
1. RemoveicemakerformFreezer.
2.  Pushtroughretainingtabbackagainstthe
mold.
3.  Pullthetroughupuntilitisclearofthemold.
4.  Replaceinreverseorder.
To Replace Ice Stripper (Figure F5)
1. Removeicemakerfromfreezer.
2. Pulloutonthestripperabout1inchback
fromthefronttheicemakertilltheretaining
tabisawayfromthetabontheicemold.
3.  Pullbackonicestrippertodisengageitfrom
frontofmoldsupporthousing.
4.  Replaceinreverseorder.
To Replace Ejector Blades (Figure F5)
1. Removeicemakerformfreezer.
2.  Removefrontcover.
3.  Removetwoscrewsholdingmountingplate
inplace.
4.  Carefullyremovemountingplate,
disengagingendoficemakercontrolarm
andejectorbladesfrommotorcoupling,
notingrelativepositionoficemakercontrol
armspring.
5.  Removelltroughandbearing.
6.  Turnbladesto12O’clockposition.
7.  Slideejectorbladesbackanduptoremove.
8.  Replaceinreverseorder.
9.  Lubricatebearingendsofejectorwith
Figure F 5
Ice Stripper
On Off Switch
Fill Trough
Ice Mold
Ice Ejector
Sensing Arm
Sensing Arm Extension
