Complaint-Ice Maker Fail to Stop at End of
Cycle
Withtheejectorbladesinthestartingposition,
checktheholdswitchterminals”C”and“NO”for
continuity.Replacetheswitchifthecontinuity
readingsareindicatingaclosedcircuit.
Complaint-Ice Maker Continues to Eject When
Container is Full.
1.  CheckforlooselinkagetotheIcemaker
controlarmshut-offswitch.Switchshould
openwhenarmisinraisedposition.Adjust,if
required.
2. Checkshut-offswitchterminals“C”and“NO”
forcontinuitywithIcemakercontrolarm
raised.Replaceswitchifcontinuityreadings
areindicatingaclosedcircuit.
Complaint-Ice Maker Produces Undersized Ice
Pieces
1. Ensurethaticemakermoldislevel.
2. Checkforpartialrestrictioninsupplylineor
watervalvestrainer.
3. Ensurethatthewaterpressuretowatervalve
issufcient.(20psimin.,120psimax.)
4. Ensurethatthewatervalveswitchisadjusted
forproperwaterll,78to83cc’s.
5. Checkthermalbondbetweenthermosat
andmold.Ifnecessary,rebondwiththermal
masticsealer.
Figure F 6
On Off Switch
(Master)
Thermostat
Thermal
Cut-Out (TCO)
Shut-Off Switch
(Sensing Arm)
Sensing Arm
Heater
Sensing Arm Spring
Sensing Arm Sensing Arm Linkage
Section F - Ice Maker
