Ice Maker Testing Procedures
Operating Cycle
OperationoftheiceMaker,waterrelling,and
controlledicestorage,requireproperfunctioning
andtimingofallcomponents.
Considerthefollowing:
•  Hasrefrigeratorbeenproperlyinstalledand
connectedtosourcesofelectricalpowerand
water?
•  Hasfreezercompartmentevaporatorpulled
downtotemperature?
•  Istheicemakerturnedon?
•  Haveseveralicemakingcyclesbeen
completedtoremovealltheairformthe
waterlines?
•Dotheejectorbladesmaketworevolutionsper
cycle?Isicestoredonbladesafterharvest?
•  Isthewatersolenoidwiredinserieswiththe
moldheater?
Operating Cycle Illustrations - Electrical
Operating Cycle Illustrations - Manual
Cycle
Tomanuallycycleicemaker:
1.  TurntheOnOffswitchtoON
2.  Pressinonswitchholdingthespringloaded
contactsetclosed,thiswillallowthemotorto
start.
3.  Holdinontheswitchfor10secondstoallow
holdswitchcontactstocloseallowingtheice
makertocontinuethroughacycle.
Thefollowingwiringdiagramsillustratetheelectricaloperationofarearmounticemaker.
1
•IceMakerconnectedtoelectricity.
•Moldtemperatureabove9°F.
•Thermostatopen.
•Motornotrotating.
•MoldHeateroff.
•ControlArminthedownposition.
•FeelerArmSwitchclosedCtoNO.
•HoldSwitchclosedCtoNC.
•WaterFillSwitchopen.
Section F - Ice Maker
