Electrolux E23CS75DSS0 - Testing the Dispenser; General Information; Service Mode

108
Section G - Ice and Water Dispenser
8.Performthefollowingtests;
9.  Followthedirectiongivenbelowforindividual
failures:
 a.FailTest8only,gotoSection2.
 b.FailTest10only,gotoSection3.
 c.FailTest11only,gotoSection4.
 d.FailTest24only,gotoSection5.
 e.FailTest28only,gotoSection6.
 f. FailTest36aonly,gotoSection7.
 g.FailTest36bonly,gotoSection8.
 h.Failledfunctiononly,gotoSection9.
10. Followthedirectiongivenbelowformultiple
failures:
 a.FailTests8,10and11,gotoSection10.
 b.FailTests10,11and24,gotoSection11.
 c.FailTests28,36aandledfunction,goto
Section12.
Testing the Dispenser
General Information
1.  Duringnormaloperation,certaincomponents
canfailindependentlywithnocascading
effecttoothericeandwaterrelated
components.Thesecomponentsarelisted
below:
 a.WaterValve
 b.AugerMotor
 c.Cube/crushSolenoid
2.  Duringnormaloperation,othercomponents
failwithacascadingeffect.These
componentsarelistedbelowwiththerelated
disabledcomponents:
  a.FreezerDoorSwitch–disablesAuger 
 Motor,Cube/crushsolenoid,Flapper 
 solenoid
  b.PaddleMicro-switch–disablesWater 
 Valve,AugerMotor,Cube/crushsolenoid,
 Flappersolenoid,automaticledillumination
  c.FlapperSolenoid–disablesAugerMotor,
 Cube/crushsolenoid
  d.FlapperMicro-switch–disablesAuger 
 Motor,Cube/crushsolenoid
3.  Duringnormaloperation,thedispenser
pocketwillbelitbyapairofLED’sonthe
iceandwatermodule.TheLED’scanbeset
tobeon100%ofthetimethrutheUIoron
whenthepaddleispressedforiceorwater.
VerifythattheLED’sfunctionproperlypriorto
enteringservicemodebelow.
4.  Denitions:
  a.ERF2500++–mainboardlocatedunder
 therefrigeratorbehindthelowerfrontpanel
  b.UI–Userinterfaceabovethedispenser
 pocket
 c. IceandWatermodule–singlepaddlesub-
assemblylocatedbehindtheUI.
Service Mode
5.  Enterservicemodebypressingandholding
FreezerDown“-“andFreezerUp“+”keys
simultaneously
6.  Ifservicemodecannotbeaccessed,goto
Section1ofthetroubleshootingowchart.
7.  PressFreshFood“+”toadvancethruthe
menuoptions;press“ON/OFF”toactuate
function
Test Passing Result
8 WaterValve Valveactuates.
10 AugerMotor Augerrunswithfreezer
doorclosed.
10a AugerMotor
SwitchClosed
Augerstopswhenfreezer
doorswitchisheldclosed
andaugermotorswitchis
allowedtoopen.
11 Cube/Crush
Solenoid
Solenoidpullsin(requires
icebuckettorelease).
24 FreezerDoor
Switch
Displays“OP”foropenand
“CL”forclosed.
28 Paddle
Microswitch
Displays“ON”when
pressedand“OFF”when
released.
36a Flapper
microswitch
Displays“OP”whenapper
isopenedmanually.
36b Flapper
solenoidand
microswitch
Flapperactuates,latches
anddisplays“OP”.
