Electrolux E23CS75DSS0 - Addendum a - Perfect Temperature Drawer; Perfect Temperature Drawer; Service Information

125
IMPORTANT
Donotoperatethedrawerwithouttheinsulation
panels.Thedrawercomeswitharemovablewine
rack
Addendum A - Perfect Temperature Drawer
Perfect Temperature Drawer
(some models)
ThePerfectTemperatureDrawerwillmountin
placeofthemeatkeeperdrawerabovethecrisper
drawers.
Figure 1
Figure 2
ON/Off
Switch
Pre-Programed
Settings
Favorite
Settings
Temp.
Display
Control
Lock
Customercontrolofthedrawerisbyamembrane
keypadatthefrontofthedrawer.Therearenine
presetselectionsandthreeuserprogrammable
selections.Theoperatingtemperatureisuser
selectablebetweenF(Fahrenheit)andC
(Centigrade).Thereisacontrol lockbutton(hold
forthreesecondstooperate)andanon/offbutton
fordraweroperation.Usetheup(∧)ordown(∨)
buttonstoscrollthroughtheselections.
The(+)and(-)buttonswillraiseandlowerthe
temperature1°perpressorbyholdingitwillscroll
upanddown.Theoperatingtemperaturecanbe
setatanypositionbetween+28°Fto+42°F.The
drawercoverisaspillsafeglassshelf.Thereare
insulatedpanelsinthebottomofthedrawertohelp
maintainaccuratetemperatures.
Service Information
Thedrawercanberemovedbyopeningand
pressingtogetherthetabsoneachsideoftheroller
trackandliftingup.Thecoversitsonfoursupports
intheliner.Itcanberemovedbyunpluggingitfrom
thecontrolhousingandthenliftingupatthefront
andpullingforward.
Themaincontrolunitforthedrawerismountedto
thelinerwithfourhooksintoslotsonthelinerand
onescrewatthetoptoholditinplace.(SeeFigure
3.)Theouterleftsideofthecontrolunithasahole
thatsealswiththeairsupplyopeningintheliner.
Italsohasaextensionwithareturnairpickupfor
circulationofairfromthedrawer.Thecontrolpanel
sectionismountedinthefrontofthedrawercover.
Thecoverhangsonthesamesupportsintheliner
thatwouldholdtheMeatorUtilityDrawer.(See
Figure4.)
Figure 4
Controlsection
Figure 3
Sectionofcontrolunittopickupcoldaircomingfrom
thefreezerfanthroughaopeninginthelinerandreturn
airfrominsidethedrawerforcirculation.
Airdischargefromcontrolunittothedrawer
- Lowerdrawertemperature
F/C ChangebetweenFahrenheitandCentigrade
+ Raisedrawertemperature
