Section C - Electronic Control System
Test 2 - Defrost Heater Test.
PushtheON/OFFpadandtheheaterwillcome
on.PushtheON/OFFpadagainandtheheater
willgooff.
Test 3 - Fresh Food Compartment
lighting test.
PushtheON/OFFpadthenopenthefooddoor 
andthefoodcompartmentlightswillcomeon 
lowandrampupPushtheON/OFFpadagainto
canceltest.
Test 8 - Water Valve , Water Dispenser
Only.
PushtheON/OFFpadactivate.PushtheON/OFF
padagaintodeactivate.NOTE:PrimaryValveonly.
Test 9 - Freezer Compartment Lighting
Test.
PushtheON/OFFpadthenopenthefooddoor 
andthefoodcompartmentlightswillcomeon 
lowandrampupPushtheON/OFFpadagainto
canceltest.
Test 10 -Auger Motor
PushtheON/OFFpadactivate.PushtheON/OFF
padagaintodeactivate.
Test 11 - Cube/Crush Solenoid
PushtheON/OFFpadactivate.PushtheON/OFF
padagaintodeactivate.
Test 12 - VCC Condenser Fan
PushtheON/OFFpadandthefanmotorwill 
runatfullspeed.PushtheON/OFFpadagainand
itwillstoprunning.
DC Load Testing
NOTE
OnlyusedwithVCCCompressor.
Test 38 - VCC Compressor
PushtheON/OFFpadandtheCompressorwirun
atfullspeed.PushtheON/OFFpadagainand 
itwillstoprunning.
NOTE
OnlyusedwithVCCCompressor.
Test 15 - Evaporator Fan
PushtheON/OFFpadandthefanwillrunatlow
speed.(LOWwillshowinfreezerdisplay)Pushthe
ON/OFFpadandthefanwillrunatfullspeed.
(HIwillshowinfreezerdisplay)PushtheON/OFF
padagainandthefanwillstoprunning.(Off 
willshowinthedisplay)
Test 22 - Damper Test
PushtheON/OFFpadandthedamperwillopen.
(OPwillshowinfreezerdisplay)PushtheON/OFF
padandthedamperwillclose.(CLwillshowin
freezerdisplay)
Digital Input Test
Test 23 - Fresh Food Door
FreezerDisplaywillshowOPopenwhendooris
openandCLwhendoorisclosed.
Test 24 - Freezer Door
FreezerDisplaywillshowOPopenwhendooris
openandCLwhendoorisclosed.
Test 26 - DTT (Defrost Limit Switch)
DisplaywillshowOPopenwhenswitchisopen
andCLwhendoorisclosed.
Test 28 - Dispenser paddle test.
PushtheON/OFFpadandpresspaddlewith 
freezerdoorclosedtotest.
Test 36 - Ice door test
PushtheON/OFFswitchandthesolenoidshould
activate.TheFreezerdisplayshouldshowtheice
doorisclosed.
Test 29 - Fresh Food Thermistor
PushtheON/OFFpadandthedisplayshould 
showa“0”ifthethermistorisgoodanda“ER” 
ifthethermistorisopenorshorted.
Test 30 - Freezer Thermistor
PushtheON/OFFpadandthedisplayshould 
showa“0”ifthethermistorisgoodanda“ER” 
ifthethermistorisopenorshorted.
Test 33 - Ambient Thermistor
PushtheON/OFFpadandthedisplayshould 
showa“0”ifthethermistorisgoodanda“ER” 
ifthethermistorisopenorshorted.
