Section C - Electronic Control System
Removethesensorfromundertheclip,disconnect
fromtheconnectorplugandreplace.Reassemble
inreverseorder.
NOTE
Totestthethermistors,checkthetemperature
inthelocationofthethermistor.Usethechart
onpageC28totestthethermistorforproper
resistanceatthetemperatureyouaremaking
yourtestat.
Food Compartment Light Switch
Thefoodcompartmentlightswitchisinstalledin
thetophingecover.Toremovethescrewsholding
thehingecoverinplaceandliftthecoverup.You
cannowremovethewiresfromtheoldswitch
andremovetheswitchformthecover.Reinstallin
reverseorder.
Freezer Compartment Light Switch
Thefreezercompartmentlightswitchisinstalledin
thetophingecover.Toremovethescrewsholding
thehingecoverinplaceandliftthecoverup.You
cannowremovethewiresfromtheoldswitch
andremovetheswitchformthecover.Reinstallin
reverseorder.
NOTE
Thislightswitchisonlycontrollingthefreezer
lighting.Thedispenserswitchislocatedinthe
freezercompartmentontheleftsideandis
controlledbytheinnerdoorpanelonthefreezer
doorcontactingtheactuatorontheswitch.
Lighting Control
Thislightingcontrolallowsthelightstorampupto
fullintensitywheneveradoorisopenedandramp
downwhenthedoorisclosed.Thelightingcontrol
ispartofthepowerboardlocatedunderthefreezer
compartmentbehindthebottomgrill.
