Electrolux E23CS75DSS0 - Installing the Heater Wire - Step 3; Condenser Replacement

73
Section E - Refrigeration System
NOTE
Takethetimetoremoveallthebendsfromthe
heater(causedfrombeingrolledup)bypulling
theheaterandbraidthroughashopragwitha
smallamountofsiliconeontheragandlayingitin
arollattheopenendoftheHotTube.Itwillmake
heaterinstallationgofaster.Usingofagood
twostage,5CFMVacuumPumpwillalsomake
heaterinstallationgofaster.
Vacuum
Pump
Connect to Condenser Outlet
Adapter and
plastic sleeve
Installingthe Heater Wire - Step 3.
1.  Removewires(withterminals)from
compressorstarter/overload.Onsome
modelsyouwillneedtodepresslocking
tabslocatedinrelayhousing(SeeDrawing
below.)
3.  Cutoffbraidatstartofheater.Stripinsulation
backabout5/16inch.Becarefulnotto
damageheaterresistancewire.Spliceheater
wireendstolooseleadsofadapterharness
withfurnishedwireconnectors.
4.  DresswiresawayformCondenserFanBlade
andanysharpedges.
5.  Securewireswithelectricaltapeas
necessary.
6.  ReinstallBackPanelforproperairowover
condenserandcompressor.
Wire splice connector to heater
Wire splice connector to heater
Red
Refrigerator
Harness
Red
White
White
Condenser Replacement
1.  Disconnectelectricalsupplytorefrigerator.
2.  Removecompressoraccesspanel.
3.  RecoverrefrigerantbyusingEPAapproved
recoverysystem.
4.  Removecondenserfanmountingscrews.
5.  Unplugfanmotorharnesslocatedinbackof
fanmotor.
6.  Removefanmotorandfanblade.
7. Afterrefrigerantiscompletelyrecovered,
disconnectinletanddischargelinesfrom
condenser.
8.  Removewhitecondenserretainerclipfrom
fanbracketandcondenser.
9.  Liftfrontofcondenserandthetworubber
gromentsoutofretainerinbaseplate.
10. Removeoldcondenseroutthebackof
cabinet.
11. Installreplacementcondenser.
12. Removeoriginallter-drier.
