Electrolux E23CS75DSS0 - Performance Data

48
PERFORMANCE DATA NO LOAD & NO DOOR OPENINGS AT MID-POINT
CONTROL SETTING
TypeAwithRun/Start
Capacitor
65°F(18°C)Ambient 90°F(32°C)Ambient
VariableSpeed Standard VariableSpeed Standard
OperatingTime 74to84% 32to40% 100% 55to65%
FreezerTemperature
-2°to2°F
-19°to-17°C
0°to4°F
-18°to-16°C
-1°to3°F
-18°to-16°C
-1°to3°F
-18°to-16°C
RefrigeratorTemperature
34°to39°F
1°to4°C
34°to39°F
1°to4°C
34°to39°F
1°to4°C
34°to39°F1°
to4°C
LowSidePressure(cut-
in)
5to12psig
43to83kPa
5to12psig
43to83kPa
N/A
5to12psig
43to83kPa
LowSidePressure
(cut-out)
-2to2psig
-14to14kPa
-2to2psig
-14to14kPa
-2to2psig
-14to14kPa
-2to2psig
-14to14kPa
HighSidePressure
(last1/3cycle)
90to105psig
621to724kPa
90to115psig
621to793kPa
120to135psig
827to931kPa
130to155psig
896to1069kPa
Wattage(last1/3cycle) 60to65 120to150 65to80 130to160
Amps(running) .7to1.1 1.0to1.4 .9to1.3 1.1to1.5
BaseVoltage 115vac(127vacmax)
DEFROST SPECIFICATIONS
CabinetSize
Thermostat Heater
Cut-in Cut-out Watts Ohms
23’,23’CD,26’ 25°F(-4°C) 47°F(8°C) 450 30
ElecrttonicTimer-(ADC)Defrost24minutesevery6-96hoursofcompressorruntime.
CONDENSER FAN MOTOR
Watts RPM Amps
3.1 1100CWOppositeShaft 0.03Running
ICE MAKER SPECIFICATIONS
Electrical 115vac(127vacmax)
Thermostat Opensat48°F(9°C),Closesat15°F(-9°C)
HeaterVoltage 85vac
ICE MAKER CONNECTOR PLUG CONNECTIONS
Wire Number Wire Color Connects to:
1 Green/Yellow Ground
2 Yellow WaterValve
3 Black Line
4 LightBlue Neutral
Section C - Electronic Control System
