Electrolux E23CS75DSS0 - Dispenser Operation

105
Section G - Ice and Water Dispenser
Figure 4
Remove two screws
Thenremovethescrewstwoscrewsatthetop
ofthecontrol.Nowyoucanliftuponthecontrol
assemblywhileyoutipitoutatthetop.Thiswill
allowyoutoremovethecontrolassemblyfromthe
door.
Withthecontroloutyoucandisconnectthemolex
plugsformthedispenserhousingtothecontrol
assembly.Thiswillallowforcompleteremovalof
thecontrol.
Disconnect Plugs
Figure 5
Withthecontrolremovedyoucannowremovethe
twoscrewsholdingthedispenserinthehousing.
(SeeFigure6)
Remove screws
115 VAC Black & Blue
12 VDC Brown & Blue
Relay to Control Door
Solenoid
Control Board
for Relay
Figure 6
DISPENSER OPERATION
Thedispenserhasauserinterfacesectioninthe
controlinthedoor.Theaugermotor,watervalve
andcubeiceareallcontrolledonthelowercontrol
board.Therearetwoconnectionsonthebackof
thecontroloneisa115VACconnectiontosupply
powertooperatethedooropeningsolenoid.The
otherisa12VDCconnectionfromthelowercontrol
boardtooperatedtherelaythatcontrolsthedoor
solenoid.(SeeFigure7)
Figure 7
Whentheactuatorispressedalowvoltagesignal
(12VDC)issenttotheuserinterfaceontheupper
controlbywayoftheactuatorswitchlocatedon
thehousingjustbehindthedoorsolenoidrelay.
(SeeFigure8)Theupperboardwillsenda
communicationtothelowerboardbasedonthe
customersselectionofWater,cubeiceorcrushed
ice.Ifwateris selected the communication will
open a tri-ack on the lower board for the water
valve. If ice is selected it will do the same thing for
the auger motor and /or cube ice solenoid.
Actuator Switch
Actuator
Figure 6
