Electrolux E23CS75DSS0 - Door Handle Mounting Instructions

11
Section A - Installation
Door Handle Mounting Instructions
1 Removehandlesfromcartonandanyotherprotectivepackaging.
2 Positionfreezerhandleendcapsoverupperandlowerpre-installedshoulderbolts(A)thatare 
fastenedintodoor,ensuringtheholesforthesetscrewsarefacingtowardstherefrigeratordoor. 
(SeeFigure1.)
3 Whileholdinghandlermlyagainstdoor,fastenupperandlowerAllensetscrews(B)withsupplied
Allenwrench.(SeeFigure1.)
4 Repeatsteps2and3toinstallrefrigeratorhandle.Ensuretheholesforthesetscrewsarefacing 
towardsthefreezerdoor.(SeeFigure2.)
NOTE
Allsetscrewsshouldbetightenedandsub-ush(Allensetscrewshouldbeseatedjustbelow
thesurfaceoftheendcap)ofhandleendcap.Theendcapsshouldbedrawntighttofreezerand
refrigeratordoorswithnogaps.
A
B
A
B
A
B
A
B
Freezer Lower End Cap Refrigerator Lower End Cap
Figure 1 Figure 2
