Section C - Electronic Control System
Control Removal and
Installation
CAUTION
Beforeservicinganypartofthecontrolsystem
theproductmustbeunplugged,thefusepulledor
circuitbakerturnedoffthepreventdamagetothe
theproductthecontrolsystemorpersonalinjury
totheservicer.
Toservicethecontrolboardyoumustremovethe
framearoundthedispenserhousingbypulling
straightoutatthetopcornerandworkingyourway
aroundtheframepullingitoutofthegroveinthe
door.
NOTE
Whenhandlingandorreplacingacontrolboardit
isimportanttheatechnicianhaveawristground
straponandconnectedtothecabinetoranother
groundingpositiontopreventstaticelectricity
fromdamagingtheboard.
Thenremovethescrewstwoscrewsatthetop
ofthecontrol.Nowyoucanliftuponthecontrol
assemblywhileyoutipitoutatthetop.Thiswill
allowyoutoremovethecontrolassemblyfromthe
door
Withthecontroloutyoucandisconnectthemolex
plugsformthedispenserhousingtothecontrol
assembly.Thiswillallowforcompleteremovalof
thecontrol.
Withthecontrolremovedyoucanremovethe
powersupplyboardfromthebackofthecontrol
byremovingthe4screwsanddisconnectingthe
wiringharnessconnectorforthepowersboardto
thecontrol.
Pushthenewcontrolboarddownintoplaceusing
cautionnottodamagetheboardontheretainer.
Withtheboardsnappedallthewaydowninplace
reinstallthecontrolboxinthetopofthefood
compartmentinreverseorderfromtheremoval
instructions.
Toservicethepowerboard(mainpowersupply),
openthefoodandfreezerdoor.Removethekick
platefromthebottomofthecabinet.Looking
throughtheopeningatthebottomofthecabinet,
ontheleftsideyoucanseetheplasticbox
containingthepowerboard.
Onescrewinthemiddleofthefrontofthebox
holdsthecontrolbox.Removethescrewandslide
thecontrolboxforward.Thebackofthecontrolbox
sitsonarail.Nowthecontrolboxcanbepulledout
fromthefrontoftherefrigerator.
