Section F - Ice Maker
6.  DisconnectTCOfromtwowirenuts.One
endisconnecttothecableassemblyand
theotherendisconnectedtothemotorand
moldheater.
7.  ReplacewithnewTCO.
8  Reassembleinreverseorder.
To Replace Ice Mold and Heater
1. Removeicemakerformfreezer.
2.  Removefrontcover.
3.  Removeicestripper.(RefertoSection“To
Replace Ice Stripper” )
4.  Removetwoscrewsthatattachmounting
platetosupporthousing.
5.  Removetwoscrewsthatattachmoldto
supportHousing.
6.  Disconnectthewirenutontherightholding
threeblackleadstogetherandseparate
them.
NOTE
Forbestoperation,thefreezertemperature
shouldbebetween-2°Fto+4°F.
NOTE
Oneblackleadisconnectedtothemoldheater.
Anotherisconnectedtothethermostatandthe
thirdleadgoestotheholdswitch.
7.  Disconnectthewirenutontheleftholding
threeblackleadstogetherandseparate
them.
8.  Separatemoldfromsupporthousing.
9.  Removehexheadscrewholdingicemaker
levelingbrackettomold.
10. Applylayerofthermalmasticsealertothe
newicemoldinthelocationthethermostat
mounts.
11. Replacepartsinreverseorder.Ensure
thatthermostatgasketisinplace.Bond
thermostattomoldwiththermalmastic
sealer.
Fault Diagnosis
Complaint - Ice Maker Fails to Start
1.  Checktoseeificemakercontrolarmis
lockedinraisedposition.
2.  Checkterminalsfromcabinetwiringto
icemakerforopencircuitinwiringor
components.
3.  Checkoperationoftheicemakerwithtest
servicecord.
4.  Checkmoldtemperatureatamounting
screw.Iftemperatureisabove15°F,freezer
airtemperatureisnotcoldenoughtoswitch
icemakerthermostattoclosedposition.If
moldisbelow9°F,manuallystarticemaker
byrotatingtimergear.Ifmotorfailstostart,
checkmotorforcontinuity.Ifmotorstarts,
thermostat,shut-offswitch,orholdswitchis
inoperative.
5.  Checkholdswitchrst.withejectorblades
inthestartingposition,checkterminals“C”
and“NC”forcontinuity.Replaceswitchif
continuityreadingsareopen.checkshut-off
switchlinkage.Thencheckterminals“NO”
and“C”forcontinuitywithicemakercontrol
arminlowestposition.Replaceswitchif
continuityreadingsareopen.Ifholdswitch
andshut-offswitchareoperative,then
replacethermostat.
Complaint-Ice Maker Fails to Complete Cycle.
1.  WithEjectorbladesat10o’clockposition,
holdswitchplungerdepressed,check
terminals“C”and“NO”forcontinuity.Replace
switchifcontinuityreadingsareopen.
2.  WithEjectorbladesat12o’clockposition,
checkshut-offswitchterminals“C”and“NC”
forcontinuity.Replacethermostatifcontinuity
readingsareopen.
3.  Withejectorbladesat4o’clockposition,
checkmoldheaterandicemakerthermostat
forcontinuity.Replaceheaterifcontinuity
readingsareopen.Ifheatershowscontinuity,
replacethermostat.
4.  CheckMotoroperationwithatestcord.
Replacemotorifitfailstostart.
