Section C - Electronic Control System
Toreinstallthedamper,makesurethedamper
doorisclosedalltheway.Thenfollowtheremoval
instructionsinreverseorder.Uecautiontomake
sureyougetthewiringconnectorpushedallthe
wayin.Makesurethesealonthedamperconnect
withthelinerandthecoversealsotherearenoair
leakswhenthedamperdoorisclosed.
Totest,setthecontrolsystemintoservicetest
mode2(evaporatorfanmotortest)andallowthe
fantorunonhighspeed.Passafeatherorsmall
ribbonaroundallsidesofthedampercover
andlookformovementindicatinganairleak.Ifa
airleakispresent,youwillneedtoremoveand
recheckthesealsandreinstallthedamper.
Thefoodcompartmenttemperaturesensoris
locatednexttotherighthandshelfsupportbracket
inaboutthemiddleofthebackwall.
Thecoveroverthetemperaturesensorcanbe
removedbypullingstrightout.Thisallowexcessto
thesensorsnappedintothebracketontheback
wall.Pullthesensoroutofthebracketandunpluge
itfromtheconnectorcomingoutofthebackofthe
liner.
Snapthenewsensorintothebracket,plugitinto
theconnector,thenpushthebracketstraightback
intotheholesintheliner.
Thefreezercompartmenttemperaturesensor
islocatedinsidethehousingthatsupportsthe
icebucket.Theaugermotorandsolenoidare
mountedintothebackcompartmentofthehousing.
CLIP
HOLDING
SENSOR
Toreplacethesenser,removetheicebucket,
thenremovethetwoscrewsatthebottomofthe
housingthatholdthehousingassemblytothethe
railsattachedtotheliner.Withthescrewsremoved
liftthehousingupabout1/2inchandpullforward.
Holdingthehousingassemblyinonehand,reach
overtheassembleyandunplugthewiringharness
fromtheconnectorcomingoutofthebackofthe
liner.Turntheassemblyaround.Thesensorisin
thetopcorner,nexttothecubeiceseloniod.
