Section C - Electrical Components
8.  Disconnecttwoleadstodefrostheater.
CAUTION
This is a good time to test the heater.
Check resistance of defrost heater using
a multimeter. Resistance should be very
close to 30 ohms. Replace defrost heater if
resistance readings are out of range.
CAUTION
Use caution not to damage suction line or cap
tube.
9.  Unclipgroundwirehookedtodraintrough.
10. Removescrewholdingevaporatorbracket
throughdraintroughtocabinet.
11. Removerivetholdingbrackettotroughand
setbracketasideforreuse.
12. Removescrewholdingdraintroughto
cabinet.
13. Liftupandpullevaporatoranddraintrough
outatbottom.
3.  Removeicecontainerandrailassembly.The
multiconnectoratbackofrailassemblymust
bedisconnectedbeforerailassemblywill
comefree.
4.  Loosenthe2screwsholdingicemakerto
rightsideofcompartmentjustenoughtolift
icemakerfree.Themulticonnectormustbe
disconnectedbeforeicemakerwillcomefree
fromcompartment.
5.  Removetworailassemblysupports.(two
screwsoneachone).
6.  Removefourscrewsfromevaporatorcover.
7.  Removevescrewsonevaporatorairduct
cover.
Figure C8
Figure C9
14. Slidedraintroughoffevaporator.
15. Removeretainerclampfrombottomof 
evaporatorthatholdsheaterinplace.
16. Grabheaterfrombottomandpullfreeof
evaporator.It’sverysnugsoyou’llneedto
usealittleforce.
17. Replacewithnewdefrostheater.
18. Re-assembleinreverseorder.
Defrost
Heater
