Section E - Refrigeration System
Figure 2
Drill 1/2 inch hole
through cabinet
1 inch below old
heat exchanger.
8.  Usinga1/2”drillbit,openholedrilledinStep
7to1/2”frombackofproduct.SeeFigure2.
9.  Removestubsofoldheatexchangerfrom
evaporatorandinstallnewheatexchanger
intoevaporator.
10. Pushheatexchangerthroughholeincabinet
(Seegures3&5.)andsetevaporatorback
inplace.
11. SlideArmor-Flexoverheatexchangeruntil
coverisagainstholeatbackofcabinet.The
excesscaptubecanbewoundaroundthe
suctionline.
12. Sealtheholeontheinsideandoutsideusing
Permagum.(SeeFigues3&5)
13. Theonepiececovercannowbeinstalled
overheatexchanger.Placeopenendof
coverwithtopofcompressorcompartment
opening.Attachcovertobackofcabinet
usingscrewsprovided.Thereisnoneedto
predrillholesasthescrewsareselfcutting.
(SeeFigure4.)
14. Sealholeandendofoldheatexchangerwith
Permagum.(SeeFigure6.)
15. ReplacrDrier-Filter.
16. Evacuateandrechargesystem.
17. Bendremainingtubingtotintomachine
compartmentopening,beingcarefulnotto
setupanyexcessnoisefromlinevibration.
(SeeFigure7.)
18. Runproducttomakesurerefrigerantis
circulating.
19. Reinstallevaporatorandmachine
compartmentcover.
Push the heat
exchanger through the
hole in the cabinet.
Installthearmorex
over the heat exchanger.
Seal hole using the
permagum.
Figure 3
Figure 4
Using screws in kit, attach
cover to back of cabinet.
Line lower cover up
with top of machine
compartment opening.
Figure 5
Using the permagum
provided in kit, seal
hole and end of old
heat exchanger.
Old heat
exchanger location
Figure 6
Using the permagum
provided in kit, seal
hole and end of old
heat exchanger.
Figure 7
Bend tubing
as shown to fit
inside machine
compartment
