Configuredeviceoptionsandpreferences
DisplayLanguagecontrolsthelanguageusedforprocessdataandmenusonthedisplay.Different
languagesareavailable,dependingonyourtransmittermodelandversion.
Procedure
SetDisplayLanguagetothedesiredoption.
6.1.2Configuretheprocessvariablesthatareshownonthedisplay
DisplayNotavailable
ProLinkII
ProLink→Conguration→Display→DisplayVarX
FieldCommunicatorCongure→ManualSetup→Display→SetUpDisplayVariables
DisplayVariablescontrolstheprocessvariablesshownonthedisplay.Thedisplaycanscrollthroughupto
15processvariablesinanyorder.Youcanconguretheprocessvariablestobedisplayedandthe
orderinwhichtheywillappear.Youcanrepeatvariables,andyoucanleaveslotsempty.
Restrictions
•YoucannotsetDisplayVariable1toNone.DisplayVariable1mustalwaysbesettoaprocessvariable.
•IfyouhavexedDisplayVariable1totheprimarymAoutput,youcannotchangethesettingof
DisplayVariable1usingthismethod.T ochangethesettingofDisplayVariable1,youmustchangethe
congurationofmAOutputProcessVariablefortheprimarymAoutput.
Note
Ifyouhaveconguredavolumeprocessvariableasadisplayvariable,andyousubsequentlychange
thesettingofVolumeFlowType,thedisplayvariableisautomaticallychangedtotheequivalentprocess
variable.Forexample,ifDisplayVariable2wassettoVolumeFlowRate,itwillbechangedtoGasStandard
VolumeFlowRate.
Procedure
1.Selectaslot.
2.SetDisplayVariabletothevariablethatyouwanttoappearinthatslot.
tExample:Displayvariableconfiguration
DisplayvariableProcessvariableassignment
DisplayVariable1
Massow
DisplayVariable2Masstotalizer
DisplayVariable3
Volumeow
DisplayVariable4Volumetotalizer
DisplayVariable5Density
