Integratethemeterwiththecontrolsystem
tExample:Cutoffinteraction
Conguration:
•mAOutputProcessVariable=MassFlowRate
•FrequencyOutputProcessVariable=MassFlowRate
•AOCutoff=10g/s
•MassFlowCutoff=15g/s
Result:Ifthemassowratedropsbelow15g/s,alloutputsrepresentingmassowwillreportzeroow.
tExample:Cutoffinteraction
Conguration:
•mAOutputProcessVariable=MassFlowRate
•FrequencyOutputProcessVariable=MassFlowRate
•AOCutoff=15g/s
•MassFlowCutoff=10g/s
Result:
•Ifthemassowratedropsbelow15g/sbutnotbelow10g/s:
−ThemAoutputwillreportzeroow.
−Thefrequencyoutputwillreporttheactualowrate.
•Ifthemassowratedropsbelow10g/s,bothoutputswillreportzeroow.
7.1.4ConfigureAddedDamping
DisplayNotavailable
ProLinkII
ProLink→Conguration→AnalogOutput→Primary/SecondaryOutput→AOAddedDamp
FieldCommunicatorCongure→ManualSetup→Inputs/Outputs→mAOutput1→mAOutputSettings→PVAddedDamping
Congure→ManualSetup→Inputs/Outputs→mAOutput2→mAOutputSettings→PVAddedDamping
AddedDampingcontrolstheamountofdampingthatwillbeappliedtothemAoutput.Itaffectsthe
reportingofmAOutputProcessVariablethroughthemAoutputonly.Itdoesnotaffectthereportingofthat
processvariableviaanyothermethod(e.g.,thefrequencyoutputordigitalcommunications),orthe
valueoftheprocessvariableusedincalculations.
Note
AddedDampingisnotappliedifthemAoutputisxed(forexample,duringlooptesting)orifthemAoutput
isreportingafault.AddedDampingisappliedwhilesensorsimulationisactive.
Procedure
SetAddedDampingtothedesiredvalue.
Thedefaultvalueis0.0seconds.
122MicroMotion9739MVDTransmitters
