Integratethemeterwiththecontrolsystem
Procedure
1.EnableBurstMode.
2.SetBurstModeOutput.
PrimaryVariable
(
ProLinkII)
PV
(FieldCommunicator)
Thetransmittersendstheprimaryvariable(PV)inthecongured
measurementunitsineachburst(e.g.,14.0g/s,13.5g/s,12.0g/s).
PVcurrent&%of
range(ProLinkII)
%range/current
(
FieldCommunicator)
ThetransmittersendsthePV’spercentofrangeandthePV’sactual
mAlevelineachburst(e.g.,25%,11.0mA).
Dynamicvars&PV
current(ProLinkII)
Process
variables/current
(
FieldCommunicator)
ThetransmittersendsPV,SV,TV,andQVvaluesinmeasurementunits
andthePV’sactualmilliampreadingineachburst(e.g.,50g/s,23°C,
50g/s,0.0023g/cm
3
,11.8mA).
Transmittervars
(ProLinkII)
Flddevvar
(
FieldCommunicator)
Thetransmittersendsfouruser-speciedprocessvariablesineach
burst.
3.Setorverifytheburstoutputvariables.
•IfyouareusingProLinkIIandyousetBurstModeOutputtoTransmitterVars(ProLinkII),setthe
fourprocessvariablestobesentineachburst:
ProLink→Conguration→Device→BurstSetup→BurstVar1–4
•Ifyouareusingthe
FieldCommunicatorandyousetBurstModeOutputtoFieldDeviceVars,set
thefourprocessvariablestobesentineachburst:
Congure→ManualSetup→Inputs/Outputs→Communications→HARTBurst
Mode→FieldDeviceVar1–4
•IfyousetBurstModeOutputtoanyotheroption,verifythattheHARTvariablesaresetas
desired.
ConfigureHARTvariables(PV,SV,TV,QV)
Display
N/A
ProLinkII
ProLink→Conguration→VariableMapping
FieldCommunicator
Notavailable
TheHARTvariablesareasetoffourvariablespredenedforHARTuse.TheHARTvariablesinclude
thePrimaryVariable(PV),SecondaryVariable(SV),TertiaryVariable(TV),andQuaternaryVariable
(QV).YoucanassignspecicprocessvariablestotheHARTvariables,andthenusestandardHART
methodstoreadorbroadcasttheassignedprocessdata.
140MicroMotion9739MVDTransmitters
