QuickstartwithProLinkII
Figure3-1ProLinkIIconnectiontoserviceport
A
B
C
D
APC
B25-to-9pinadapter,ifnecessary;orRS-232toUSBadapter,ifnecessary
CRS-232toRS-485signalconverter
DTransmitter
Notes
•Thisgureshowsaserialportconnection.AUSBportconnectionisalsoavailable.
4.StartProLinkII.
5.ChooseConnection→ConnecttoDevice.
6.SetProtocoltoServicePort.
Tip
Serviceportconnectionsusestandardconnectionparametersandastandardaddress.Youdonot
needtocongurethemhere.
7.SettheCOMPortvaluetothePCCOMportthatyouareusingforthisconnection.
8.ClickConnect.
Iftheconnectionissuccessful:
•Thestatusbarinthemainwindowisupdatedtoshowanactiveconnection.
•TheProcessVariableswindoworCommissioningWizardwindowisdisplayed.
28MicroMotion9739MVDTransmitters
