QuickstartwithProLinkII
Figure3-2ProLinkIIconnectiontoHARTclips
A
B
D
C
APC
BHARTinterface
C250–600Ωresistance
DTransmitter
Notes
•Thisgureshowsaserialportconnection.AUSBportconnectionisalsoavailable.
2.ToconnecttoapointinthelocalHARTloop,attachtheleadsfromthesignalconvertertoany
pointintheloopandaddresistanceasnecessary.SeeFigure3-3.
ProLinkIImustbeconnectedacrossaresistanceof250–600Ω.
30MicroMotion9739MVDTransmitters
