Emerson Micro Motion 9739 MVD

QuickstartwithProLinkII
Figure3-6ProLinkIIconnectiontoanRS-485networkusingHART
A
B
C
D
E
F
APC
B25-to-9pinadapter,ifnecessary
CRS-485toRS-232signalconverter
D120-Ω,1/2-wattterminatingresistorsatbothendsofthesegment,ifnecessary
EDCSorPLC(Auto-detectcommunication)
FTransmitter
Notes
•Thisgureshowsaserialportconnection.AUSBportconnectionisalsoavailable.
5.Toconnecttoapointinamultidropnetwork,attachtheleadsfromthesignalconvertertoany
pointinthewire.SeeFigure3-7.
ConfigurationandUseManual
35
