QuickstartwiththeFieldCommunicator
Figure4-1FieldCommunicatorconnectiontoHARTclips
C
B
A
AFieldCommunicator
B250–600Ωresistance
CTransmitter
2.ToconnecttoapointinthelocalHARTloop,attachtheleadsfromtheFieldCommunicatortoany
pointintheloopandaddresistanceasnecessary.SeeFigure4-2.
The
FieldCommunicatormustbeconnectedacrossaresistanceof250–600Ω.
Figure4-2FieldCommunicatorconnectiontolocalHARTloop
A
B
C
AFieldCommunicator
B250–600Ωresistance
CTransmitterterminals
ConfigurationandUseManual
