PROline Prosonic Flow 93 FOUNDATION Fieldbus 1 Notes on using this manual
Endress+Hauser 7
1 Notes on using this manual
There are various ways of locating the description of a function of your choice in the
manual:
1.1 Using the table of contents to locate a function
description
The designations of all the cells in the function matrix are listed in the table of contents.
You can use these unambiguous designations, (such as MEASURED VARIABLES,
USER INTERFACE, TOTALIZERS, etc.), to choose whichever functions are applicable to
a particular set of conditions.
The page references show you exactly where to find the detailed descriptions of the
functions in question. The table of contents is on Page 5.
1.2 Using the graphic of the function matrix to locate a
function description
This step-by-step, top-down approach starts with the blocks, the highest level of the
matrix, and works down through the matrix to the description of the function you need:
1. All blocks available, and their related groups are illustrated on Page 10. Select the
block (or the group within the block) which you need for your application and use the
page reference to locate the information corresponding to the next level.
2. The page in question contains a graphic showing of the block with all its subordinate
groups, function groups and functions.
Select the function which you need for your application and use the page reference
to locate the detailed function description.
1.3 Using the index of the function matrix to locate a
function description
Each “cell” in the function matrix (blocks, groups, function groups, functions) has a
unique identifier in the form of a code consisting of one or three letters or a three- or four-
digit number. The code identifying a selected “cell” appears at the top right on the local
display.
Fig. 1: Codes of the function groups and functions on the local display
The function-matrix index lists the codes for all the available “cells” in alphabetic and
consecutive order, complete with the page references for the corresponding functions.
The index to the function matrix is on Page 79.
F06-93FFxxxx-20-xx-xx-en-000
