PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Transducer Blocks (transmission blocks)
Endress+Hauser 105
3.6 Diagnosis
The status of the device is displayed via the BLOCK_ERR (see Page 107) and
“Transducer Error” (see Page 108) parameters (specified in the FOUNDATION Fieldbus
Specification) of the Transducer Block TRANSDUCER_DIAG (diagnosis, base
index 1600).
Note!
Although these parameters are available in other Transducer Blocks, the correct values
are only displayed in the Transducer Block TRANSDUCER_DIAG (diagnosis, base
index 1600).
Detailed information on the current device status and any pending errors is shown in the
Transducer Block TRANSDUCER_DIAG (base index 1600) in the “Diagnosis - Actual
System Condition” parameter, (see Page 156). More information on eliminating errors
can be found in the Operating Instructions for PROline Prosonic Flow 93 FOUNDATION
Fieldbus, BA 078D/06/en.
3.7 Access to manufacturer-specific parameters
To access the manufacturer-specific parameters, the following requirements must be
met:
1. Hardware write protection must be disabled (see Operating Instructions for PROline
Prosonic Flow 93 FOUNDATION Fieldbus, BA078D/06/en, Section 5.4).
2. The correct code must be entered in the "Un/Locking - Access Code" parameter,
(see Page 109).
