Endress+Hauser Proline Prosonic Flow 93 Function Manual

PROline Prosonic Flow 93 FOUNDATION Fieldbus 3 Block MEASURED VARIABLES
Endress+Hauser 13
3.1.2 Function group: MAIN VALUES CH2
MEASURED
VARIABLES
A
Þ
MEASURED VALUES AAA
Þ
MAIN VALUES CH1 000
ß
MAIN VALUES CH2 006
Function description
MEASURED VARIABLES → MEASURED VALUES → MAIN VALUES CH2
Use this function group to display the channel 2 measured values currently measured.
 Note!
• The engineering units of all the measured variables shown here can be set in the “SYSTEM UNITS”
group.
• If the fluid in the pipe flows backwards, a negative sign prefixes the flow reading on the display.
VOLUME FLOW CH2
(0061)
Displays the volume flow currently measured, (channel 2).
Display:
5-digit floating-point number, including unit and sign
(e.g. 5.5445 dm³/min; 1.4359 m³/h; -731.63 gal/d; etc.)
SOUND VELOCITY CH2
(0062)
Displays the sound velocity currently measured in the liquid, (channel 2).
Display:
5-digit fixed-point number, incl. units
(e.g. 1400.0 m/s, 5249.3 ft/s)
FLOW VELOCITY CH2
(0063)
Displays the flow velocity currently measured, (channel 2).
Display:
5-digit floating-point number, including unit and sign
(e.g. 8.0000 m/s, 26.247 ft/s)
SIGNAL STRENGTH
CH2
(0067)
Displays the signal strength, (channel 2).
Display:
4-digit fixed-point number
(e.g. 80.0)
 Note!
To ensure reliable measurement takes place, Prosonic Flow requires a signal
strength of > 30.
