Endress+Hauser Proline Prosonic Flow 93 Function Manual

PROline Prosonic Flow 93 FOUNDATION Fieldbus 5 Block USER INTERFACE
Endress+Hauser 31
100% VALUE
(2221)
 Note!
This function is not available unless one of the following options was selected
in the ASSIGN (2220) function:
• VOLUME FLOW % CH1
• VOLUME FLOW % CH2
• CALCULATED VOLUME FLOW %
Use this function to define the flow value to be shown on the display as the
100% value.
User input:
5-digit floating-point number
Factory setting:
Depends on country, [value] / [dm³...m³ or US-gal...US-Mgal]
FORMAT
(2222)
Use this function to define the maximum number of places after the decimal
point for the second value displayed in the main line.
Options:
XXXXX. - XXXX.X - XXX.XX - XX.XXX -X.XXXX
Factory setting:
X.XXXX
 Note!
• Note that this setting only affects the reading as it appears on the display, it
has no influence on the accuracy of the system's calculations.
• The places after the decimal point as computed by the measuring device
cannot always be displayed, depending on this setting and the engineering
unit. In these instances an arrow appears on the display between the
measured value and the engineering unit, (e.g. 1.2
→ m³/h), indicating that
the measuring system is computing with more decimal places than can be
shown on the display.
Function description
USER INTERFACE → MAIN LINE → MULTIPLEX
