PROline Prosonic Flow 93 FOUNDATION Fieldbus 7 Block BASIC FUNCTION
Endress+Hauser 51
7.1.2 Function group: FUNCTION BLOCKS
BASIC FUNCTION G Þ FOUNDATION FIELDBUS GGA Þ CONFIGURATION 620
ß
FUNCTION BLOCKS 622
Function description
BASIC FUNCTION → FOUNDATION FIELDBUS → FUNCTION BLOCKS
BLOCK SELECTION
(6220)
Use this function to select a function block whose value and status is shown
in the subsequent functions.
Options:
ANALOG INPUT 1
ANALOG INPUT 2
ANALOG INPUT 3
ANALOG INPUT 4
ANALOG INPUT 5
ANALOG INPUT 6
ANALOG INPUT 7
ANALOG INPUT 8
PID
Factory setting:
ANALOG INPUT 1
OUT VALUE
(6221)
Displays the output value OUT, incl. unit and status, of the Analog Input or
PID function block selected in the BLOCK SELECTION (6220) function.
PID_IN VALUE
(6222)
 Note!
This function is not available unless “PID” was selected in the BLOCK
SELECTION (6220) function.
Display:
Displays the controlled variable IN, incl. unit and status, of the PID function
block.
CASCADE IN
(6223)
 Note!
This function is not available unless “PID” was selected in the BLOCK
SELECTION (6220) function.
Display:
Displays the analog setpoint value, incl. unit and status, taken over from an
external function block.
