Endress+Hauser Proline Prosonic Flow 93 Function Manual

3 Block MEASURED VARIABLES PROline Prosonic Flow 93 FOUNDATION Fieldbus
12 Endress+Hauser
3.1 Group MEASURED VALUES
3.1.1 Function group: MAIN VALUES CH1
MEASURED
VARIABLES
A
Þ
MEASURED VALUES AAA
Þ
MAIN VALUES CH1 000
Function description
MEASURED VARIABLES → MEASURED VALUES → MAIN VALUES CH1
Use this function group to display the channel 1 measured values currently measured.
 Note!
• The engineering units of all the measured variables shown here can be set in the “SYSTEM UNITS”
group.
• If the fluid in the pipe flows backwards, a negative sign prefixes the flow reading on the display.
VOLUME FLOW CH1
(0001)
Displays the volume flow currently measured, (channel 1).
Display:
5-digit floating-point number, including unit and sign
(e.g. 5.5445 dm³/min; 1.4359 m³/h; -731.63 gal/d; etc.)
SOUND VELOCITY CH1
(0002)
Displays the sound velocity currently measured in the liquid (channel 1).
Display:
5-digit fixed-point number, incl. units
(e.g. 1400.0 m/s, 5249.3 ft/s)
FLOW VELOCITY CH1
(0003)
Displays the flow velocity currently measured (channel 1).
Display:
5-digit floating-point number, including unit and sign
(e.g. 8.0000 m/s, 26.247 ft/s)
SIGNAL STRENGTH
CH1
(0007)
Displays the signal strength (channel 1).
Display:
4-digit fixed-point number
(e.g. 80.0)
 Note!
To ensure reliable measurement takes place, Prosonic Flow requires a signal
strength of > 30.
