7 Block BASIC FUNCTION PROline Prosonic Flow 93 FOUNDATION Fieldbus
66 Endress+Hauser
WIRE LENGTH
(6885)
 Note!
This function is not available unless “CLAMP ON” is set in the MEASUREMENT
function (6880, see Page 63), and the number of traverses selected in the
SENSOR CONFIGURATION function (6882, see Page 65) is 1 or 3.
Displays the wire length for mounting the sensors at the correct distance.
Display:
Max. 5-digit number, including unit (e.g. 200 mm)
SENSOR DISTANCE
(6886)
Displays the distance between sensor 1 and sensor 2 as a length
measurement.
Display:
Max. 5-digit number, including unit (e.g. 200 mm)
ARC LENGTH
(6887)
 Note!
This function is not available unless “INSERTION” is set in the MEASUREMENT
function (6880, see Page 63), and “DUAL PATH” was selected in the SENSOR
CONFIGURATION function (6882, see Page 65).
Displays the arc length on the pipe.
Display:
Max. 5-digit number, including unit (e.g. 200 mm)
PATH LENGTH
(6888)
 Note!
This function is not available unless “INSERTION” is selected in the
MEASUREMENT function (6880, see Page 63).
Displays the path length.
Display:
Max. 5-digit number, including unit (e.g. 200 mm)
Function description
BASIC FUNCTION → SENSOR DATA (CH1...CH2) → SENSOR PARAMETER
