6.4 STATUS Command Client
þ
eCNA
The Status command can be used by the client to request the status of various functions.
Command
CMD,STS,psn,code,checksum<CR><LF>
Status Command Message Format
Name Description
CMD, Start of Message string (This parameter is always “CMD”).
STS, Status Command string (This parameter is always “STS”).
psn, Packet sequence number (0 to 65535). Can be used to match responses with commands, otherwise always 0.
code, Status code. (This parameter must contain any one of the following status code strings).
CTRLST Control State.
STPST Stopped State.
CUENO Cue Number.
DP1CF Digital 1 Power control flag.
DP1OS Digital 1 Power output status.
DV1CF Digital 1 Video control flag.
DV1OS Digital 1 Video output status.
DP2CF Digital 2 Power control flag.
DP2OS Digital 2 Power output status.
DV2CF Digital 2 Video control flag.
DV2OS Digital 2 Video output status.
FPOS Film Projector output status.
FCOOS Film Changeover output status.
SPCF Slide (Aux) Projector control flag.
SPOS Slide (Aux) Projector output status.
SYNC Sync Mode.
RESET eCNA Power up and other CPU reset.
SEGIDX Segment index number.
SEGTXT Segment name.
CAICMD CAI command access flag.
PROGN Program Number.
XTMR Exception timer status.
WAITEV ‘Wait Event’ instruction status.
GTMR,n General purpose timer status. n = timer number
checksum Checksum (0 to 65535). Unsigned 16-bit decimal sum of all preceding characters or wildcard ‘??’
<CR> Terminating carriage return. (ASCII control character, 0x0D)
<LF> Terminating line feed. (ASCII control character, 0x0A)
