6.19 Command Summary
All Commands and Responses end with a checksum, carriage return and line feed. Checksum = 0 to 65535. Carriage Return = 0Dh. Line Feed = 0Ah.
FUNCTION
COMMAND RESPONSE
REF.
ASCII
Command
Code
ASCII
Function
Code
Packet
Sequence
Number
ASCII
Parameters
Request
Ack
ASCII
Response
Code
ASCII
Function
Code
Packet
Sequence
Number
Error
Number
ASCII
Parameters
Read Clock CMD, RCK, 0-65535, RSP, RCK, 0-65535, 0-999, yyyy,mm,dd,hh,mm,ss,ttt,
Set Clock CMD, SCK, 0-65535, yyyy,mm,dd,hh,mm,ss,ttt, RSP, SCK, 0-65535, 0-999,
Get Control State
Status
CMD, STS, 0-65535, CTRLST, RSP, STS, 0-65535, 0-999, IDL, | RUN,
Get Cue Number CMD, STS, 0-65535, CUENO, RSP, STS, 0-65535, 0-999, 0 - 20,
Get Stopped State
Status
CMD, STS, 0-65535, STPST, RSP, STS, 0-65535, 0-999, OK, | STP, | FLT, | FIR,
Get Digital 1 Power
Control Flag Status
CMD, STS, 0-65535, DP1CF, RSP, STS, 0-65535, 0-999, NO, | D1P,
Get Digital 1 Power
Output Status Flag
CMD, STS, 0-65535, DP1OS, RSP, STS, 0-65535, 0-999, NO, | D1P,
Get Digital 1 Video
Control Flag
CMD, STS, 0-65535, DV1CF, RSP, STS, 0-65535, 0-999, NO, | D1V,
Get Digital 1 Video
Output Status Flag
CMD, STS, 0-65535, DV1OS, RSP, STS, 0-65535, 0-999, NO, | D1V,
Get Digital 2 Power
Control Flag
CMD, STS, 0-65535, DP2CF, RSP, STS, 0-65535, 0-999, NO, | D2P,
Get Digital 2 Power
Output Status Flag
CMD, STS, 0-65535, DP2OS, RSP, STS, 0-65535, 0-999, NO, | D2P,
Get Digital 2 Video
Control Flag
CMD, STS, 0-65535, DV2CF, RSP, STS, 0-65535, 0-999, NO, | D2V,
Get Digital 2 Video
Output Status
CMD, STS, 0-65535, DV2OS, RSP, STS, 0-65535, 0-999, NO, | D2V,
Get Film Projector
Output Status
CMD, STS, 0-65535, FPOS, RSP, STS, 0-65535, 0-999, NO, | PJM,
Get Film Changeover Douser
Output Status
CMD, STS, 0-65535, FCOOS, RSP, STS, 0-65535, 0-999, NO, | C/O,
Get Slide (Aux) Projector
Control Flag
CMD, STS, 0-65535, SPCF, RSP, STS, 0-65535, 0-999, NO, | AUX,
Get Slide (Aux) Projector
Output Status
CMD, STS, 0-65535, SPOS, RSP, STS, 0-65535, 0-999, NO, | AUX,
Get Sync Mode Status CMD, STS, 0-65535, SYNC, RSP, STS, 0-65535, 0-999, NO, | YES,
Get CPU Reset Status CMD, STS, 0-65535, RESET, RSP, STS, 0-65535, 0-999, 0 - 255,
Get Segment Index Number CMD, STS, 0-65535, SEGIDX, RSP, STS, 0-65535, 0-999, 0 - 9,
Get Segment Name CMD, STS, 0-65535, SEGTXT, RSP, STS, 0-65535, 0-999, a,
Get CAI Command Access
Flag
CMD, STS, 0-65535, CAICMD, RSP, STS, 0-65535, 0-999, OK, | BLK,
Get Program Number CMD, STS, 0-65535, PROGN, RSP, STS, 0-65535, 0-999, 0 - 9,
Get Exception Timer Status CMD, STS, 0-65535, XTMR, RSP, STS, 0-65535, 0-999, n,d,m,s,
Get Wait Event Instruction
Status
CMD, STS, 0-65535, WAITEV, RSP, STS, 0-65535, 0-999, n,s,
Get GP Timer Status CMD, STS, 0-65535, GTMR,n, RSP, STS, 0-65535, 0-999, n,e,s,mm,ss,
Exchange Status CMD, XST, 0-65535, < client status record>, RSP, XST, 0-65535, 0-999, <eCNA status record>,
Report Status CMD, RST, 0-65535, RSP, RST, 0-65535, 0-999, <eCNA status record>,
Report Id CMD, RID, 0-65535, RSP, RID, 0-65535, 0-999, n,v,s,
Start Program CMD, EVT, 0-65535, STA, Y/N RSP, EVT, 0-65535, 0-999,
Stop Program CMD, EVT, 0-65535, STP, Y/N RSP, EVT, 0-65535, 0-999,
Fault CMD, EVT, 0-65535, FLT, Y/N RSP, EVT, 0-65535, 0-999,
Cue Program CMD, EVT, 0-65535, CUE, Y/N RSP, EVT, 0-65535, 0-999,
Abort Program CMD, EVT, 0-65535, ABT Y/N RSP, EVT, 0-65535, 0-999,
Cancel Alarm CMD, EVT, 0-65535, CNL, Y/N RSP, EVT, 0-65535, 0-999,
Reset Fault CMD, EVT, 0-65535, RES, Y/N RSP, EVT, 0-65535, 0-999,
Set Program Number CMD, EVT, 0-65535, PGM,d, Y/N RSP, EVT, 0-65535, 0-999,
Set Program and Run CMD, EVT, 0-65535 SPR,d, Y/N RSP, EVT, 0-65535, 0-999,
Start Exception Timer CMD, EVT, 0-65535, SXT,d,m,s, Y/N RSP, EVT, 0-65535, 0-999,
Cue Program CMD, EVT, 0-65535, NXQ,d, Y/N RSP, EVT, 0-65535, 0-999,
Block Commands CMD, EVT, 0-65535, CAI,d,m, Y/N RSP, EVT, 0-65535, 0-999,
Start Macro CMD, EVT, 0-65535, MAC,n Y/N RSP, EVT, 0-65535, 0-999,
Set/Clear GP Timer CMD, EVT, 0-65535, SGT,n,m,s, Y/N RSP, EVT, 0-65535, 0-999,
Get All Event Logs CMD, LOG, 0-65535, GETALL, Y/N RSP, LOG, 0-65535, 0-999, <all event logs>
Clear Log Buffer CMD, LOG, 0-65535, CLRBUF, Y/N RSP, LOG, 0-65535, 0-999,
Clear Log Show Number CMD, LOG, 0-65535, CLRSSQ, Y/N RSP, LOG, 0-65535, 0-999,
Enable Event Report CMD, CFG, 0-65535, RPTON, Y/N RSP, CFG, 0-65535, 0-999,
Disable Event Report CMD, CFG, 0-65535, RPTOFF, Y/N RSP, CFG, 0-65535, 0-999,
Enable Event Log CMD, CFG, 0-65535, LOGON, Y/N RSP, CFG, 0-65535, 0-999,
Disable Event Log CMD, CFG, 0-65535, LOGOFF, Y/N RSP, CFG, 0-65535, 0-999,
Enable Macro Calls Logging CMD, CFG, 0-65535, OPT1ON, Y/N RSP, CFG, 0-65535, 0-999,
Disable Macro Calls Logging CMD, CFG, 0-65535, OPT1OFF, Y/N RSP, CFG, 0-65535, 0-999,
