Command Summary (continued)
FUNCTION
COMMAND RESPONSE
REF.
ASCII
Command
Code
ASCII
Function
Code
Packet
Sequence
Number
ASCII
Parameters
Request
Ack
ASCII
Response
Code
ASCII
Function
Code
Packet
Sequence
Number
Error
Number
ASCII
Parameters
Enable Status/Ctrl Message CMD, CFG, 0-65535, STMON, Y/N RSP, CFG, 0-65535, 0-999,
Disable Status/Ctrl Message CMD, CFG, 0-65535, STMOFF, Y/N RSP, CFG, 0-65535, 0-999,
Lights: House Up CMD, OUT, 0-65535, HLUP, Y/N RSP, OUT, 0-65535, 0-999,
Lights: House Mid 1 CMD, OUT, 0-65535, HLMID1, Y/N RSP, OUT, 0-65535, 0-999,
Lights: House Mid 2 CMD, OUT, 0-65535, HLMID2, Y/N RSP, OUT, 0-65535, 0-999,
Lights: House Down CMD, OUT, 0-65535, HLDOWN, Y/N RSP, OUT, 0-65535, 0-999,
Lights: House None CMD, OUT, 0-65535, HLNONE, Y/N RSP, OUT, 0-65535, 0-999,
Lights: Stage Up CMD, OUT, 0-65535, SLUP, Y/N RSP, OUT, 0-65535, 0-999,
Lights: Stage Down CMD, OUT, 0-65535, SLDOWN, Y/N RSP, OUT, 0-65535, 0-999,
Lights: Stage None CMD, OUT, 0-65535, SLNONE, Y/N RSP, OUT, 0-65535, 0-999,
Curtain Open: CMD, OUT, 0-65535, CURTOPEN, Y/N RSP, OUT, 0-65535, 0-999,
Curtain Close: CMD, OUT, 0-65535, CURTCLOS, Y/N RSP, OUT, 0-65535, 0-999,
Curtain None: CMD, OUT, 0-65535, CURTNONE, Y/N RSP, OUT, 0-65535, 0-999,
Masking: Flat CMD, OUT, 0-65535, MSKFLAT, Y/N RSP, OUT, 0-65535, 0-999,
Masking: Scope CMD, OUT, 0-65535, MSKSCOPE, Y/N RSP, OUT, 0-65535, 0-999,
Masking: Special CMD, OUT, 0-65535, MSKSPECL, Y/N RSP, OUT, 0-65535, 0-999,
Masking: None CMD, OUT, 0-65535, MSKNONE, Y/N RSP, OUT, 0-65535, 0-999,
Lens: Flat CMD, OUT, 0-65535, LENSFLAT, Y/N RSP, OUT, 0-65535, 0-999,
Lens: Scope CMD, OUT, 0-65535, LENSCOPE, Y/N RSP, OUT, 0-65535, 0-999,
Lens: Special CMD, OUT, 0-65535, LENSPECL, Y/N RSP, OUT, 0-65535, 0-999,
Lens: None CMD, OUT, 0-65535, LENNONE, Y/N RSP, OUT, 0-65535, 0-999,
Sound: Aux 1 CMD, OUT, 0-65535, SNDAUX1, Y/N RSP, OUT, 0-65535, 0-999,
Sound: Aux 2 CMD, OUT, 0-65535, SNDAUX2, Y/N RSP, OUT, 0-65535, 0-999,
Sound: Digital 1 CMD, OUT, 0-65535, SNDDIG1, Y/N RSP, OUT, 0-65535, 0-999,
Sound: Digital 2 CMD, OUT, 0-65535, SNDDIG2, Y/N RSP, OUT, 0-65535, 0-999,
Sound: Mono CMD, OUT, 0-65535, SNDMONO, Y/N RSP, OUT, 0-65535, 0-999,
Sound: Mute On CMD, OUT, 0-65535, MUTEON, Y/N RSP, OUT, 0-65535, 0-999,
Sound: Mute Off CMD, OUT, 0-65535, MUTEOFF, Y/N RSP, OUT, 0-65535, 0-999,
Sound: Non-Sync CMD, OUT, 0-65535, SNDNSYNC, Y/N RSP, OUT, 0-65535, 0-999,
Sound: SR CMD, OUT, 0-65535, SNDSR, Y/N RSP, OUT, 0-65535, 0-999,
Sound: SVA CMD, OUT, 0-65535, SNDSVA, Y/N RSP, OUT, 0-65535, 0-999,
Sound: None CMD, OUT, 0-65535, SNDNONE, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 1: On CMD, OUT, 0-65535, OUT1ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 1: Off CMD, OUT, 0-65535, OUT1OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 2: On CMD, OUT, 0-65535, OUT2ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 2: Off CMD, OUT, 0-65535, OUT2OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 3: On CMD, OUT, 0-65535, OUT3ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 3: Off CMD, OUT, 0-65535, OUT3OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 4: On CMD, OUT, 0-65535, OUT4ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 4: Off CMD, OUT, 0-65535, OUT4OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 5: On CMD, OUT, 0-65535, OUT5ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 5: Off CMD, OUT, 0-65535, OUT5OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 6: On CMD, OUT, 0-65535, OUT6ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 6: Off CMD, OUT, 0-65535, OUT6OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 7: On CMD, OUT, 0-65535, OUT7ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 7: Off CMD, OUT, 0-65535, OUT7OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 8: On CMD, OUT, 0-65535, OUT8ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 8: Off CMD, OUT, 0-65535, OUT8OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 9: On CMD, OUT, 0-65535, OUT9ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 9: Off CMD, OUT, 0-65535, OUT9OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 10: On CMD, OUT, 0-65535, OUT10ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 10: Off CMD, OUT, 0-65535, OUT10OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 11: On CMD, OUT, 0-65535, OUT11ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 11: Off CMD, OUT, 0-65535, OUT11OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 12: On CMD, OUT, 0-65535, OUT12ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 12: Off CMD, OUT, 0-65535, OUT12OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 13: On CMD, OUT, 0-65535, OUT13ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 13: Off CMD, OUT, 0-65535, OUT13OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 14: On CMD, OUT, 0-65535, OUT14ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 14: Off CMD, OUT, 0-65535, OUT14OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 15: On CMD, OUT, 0-65535, OUT15ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 15: Off CMD, OUT, 0-65535, OUT15OFF, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 16: On CMD, OUT, 0-65535, OUT16ON, Y/N RSP, OUT, 0-65535, 0-999,
Aux Out 16: Off CMD, OUT, 0-65535, OUT16OFF, Y/N RSP, OUT, 0-65535, 0-999,
