8.2 39445 Termination Schedule

TB1 is used for the LSN and LIN field connections. The LSN is not used on the eCNA-10. The LIN

connections on TB1 are normally not required (P2 and P3 headers are used instead).

TB1 Name Description / Comment

1 LSN Data +

Local Sync Network communications tie point only. Not

used on the eCNA-10.

2 LSN Data -

3 LSN Shield

4 LIN Data +

Local I/O Network serial data connections.5 LIN Data -

6 LIN Shield

7 LIN Return (-)

+18 Volts DC Power from the Main Control Board.

8 LIN Power (+)

TB2 and TB3 are the high power relay field connections.

TB2 Name Description / Comment

1 Out 5 COM This is a normally open high power contact. It’s function

can be software configured.

2 Out 5 N.O.

TB3 Name Description / Comment

1 Slide Projector COM Normally open high power contact. The function of this

output can be re-defined in software.

2 Slide Projector N.O.
