4.3.28 Programs
A program is a series of instructions that are executed as they are encountered. The Wait Cue
instruction is a special instruction that causes the program to wait for a cue event before continuing.
Many instructions have an associated offset time which allow time-delayed execution. The eCNA-10
can store up to nine programs. A macro is similar to a program but is used differently. The eCNA-10
can store up to fifty macros.
4.3.29 Program and Macro Instructions
Program and Macro Instructions
Instruction Parameters / Offset Time
<< blank >> n/a
House Lights Up dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
House Lights Down dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
House Lights Mid 1 dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
House Lights Mid 2 dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
House Lights None dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
Stage Lights Up dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
Stage Lights Down dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
Stage Lights None dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
Curtain Open dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
Curtain Close dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
Curtain None dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
Slide Projector On dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
Slide Projector Off dd:dd dd:dd = 0:00 to 59:59 minutes:seconds
* Wait Cue d d = 0 to 20
* Wait dd:dd dd:dd = 0:00 to 99:99 minutes:seconds
Aux m1 m2 dd:dd m1 = Out1:Flag Name to Out16:Flag Name m2 = On, Off, No-op, Toggle
dd:dd = 0:00 to 99:99 minutes:seconds
Volume d1 dB Fade Time d2 dd:dd d1 = -50.0 to +10.0 dB d2 = 0 to 10 seconds
dd:dd = 0:00 to 99:99 minutes:seconds
m1 Lights m2 dd:dd m1 = House; Stage; Zone 3 to Zone 16 m2 = Up; Down; Mid 1; Mid 2; None
dd:dd = 0:00 to 59:59 minutes:seconds
Sound: m dd:dd m = Non-Sync; Mono; SVA; SR; Digital 1; Aux 1; Digital 2; Aux 2; Mute On; Mute Off; None
dd:dd = 0:00 to 59:59 minutes:seconds
Masking: m dd:dd m = Flat; Scope; Special
dd:dd = 0:00 to 59:59 minutes:seconds
Projector: m dd:dd m = Digital 1 Pwr Off; Digital 1 Pwr On; Digital 1 Vid Off; Digital 1 Vid On;
Digital 2 Pwr Off; Digital 2 Pwr On; Digital 2 Vid Off; Digital 2 Vid On
dd:dd = 0:00 to 59:59 minutes:seconds
Bypass: m dd:dd m = Off; On; No-op
dd:dd = 0:00 to 59:59 minutes:seconds
CAI Commands: m1 m2 m1 = Ch 1; Ch 2; Ch3 m2 = Allow; Block
Segment m m dd:dd m = Seg 0 to Seg 29
m = Tmr1 to Tmr15
dd:dd = 0:00 to 99:99 minutes:seconds
* Wait Event: d d = 0 to 20
Call Macro: d m dd:dd d =0:No-op to 50:
m = Tmr1 to Tmr15
dd:dd = 0:00 to 99:99 minutes:seconds
CAI SendFx: d1: m1 m2 dd:dd d1 = 1 to 30 m1 = SendFx Name m2 = Tmr1 to Tmr15
dd:dd = 0:00 to 99:99 minutes:seconds
Lens/Masking: m dd:dd m = Flat; Scope; Special
dd:dd = 0:00 to 59:59 minutes:seconds
Lens: m dd:dd m = Flat; Scope; Special
dd:dd = 0:00 to 59:59 minutes:seconds
Set Timer: m dd:dd m = Tmr1 to Tmr15
dd:dd = 0:00 to 99:99 minutes:seconds
Timer: m1 m2 m1 = 1 to 10 m2 = Pause; Resume
Display Timer: m m = Tmr1 to Tmr15
** If (flag): m1 m2 m3 m1 = Status and Control Flags
m2 = Off; On
m3 = Then Exit; Goto 1 - 16
