6.5 OUTPUT Command Client
þ
eCNA
The Output Command allows the client to directly control individual outputs on the eCNA. A response
from the eCNA is optional.
Command
CMD,OUT,psn,code,yn,checksum<CR><LF>
OUTPUT Command Message Format
Parameter Description
CMD, Start of Message string (This parameter is always “CMD”).
OUT, Output Command string (This parameter is always “OUT”).
psn, Packet sequence number (0 to 65535). Can be used to match responses with commands, otherwise always 0.
code, Output code. (This parameter must contain one of the following output code strings).
HLUP House Lights Up
HLDOWN House Lights Down
HLMID1 House Lights Mid 1
HLMID2 House Lights Mid 2
HLNONE House Lights None
SLUP Stage Lights Up
SLDOWN Stage Lights Down
SLNONE Stage Lights None
CURTOPEN Curtain Open
CURTCLOS Curtain Close
CURTNONE Curtain None
MSKFLAT Masking Flat
MSKSCOPE Masking Scope
MSKSPECL Masking Special
SNDNONE Sound None
LENFLAT Lens Flat
LENSCOPE Lens Scope
LENSPECL Lens Special
LENNONE Lens None
SNDAUX1 Sound Aux 1
SNDAUX2 Sound Aux 2
SNDDIG1 Sound Digital 1
SNDDIG2 Sound Digital 2
SNDMONO Sound Mono
SNDNONE Sound None
MUTEON Sound Mute On
MUTEOFF Sound Mute Off
SNDNSYNC Sound Non-Sync
SNDSR Sound SR
SNDSVA Sound SVA
OUTxON Aux Out x On (where x is 1 through 16)
OUTxOFF Aux Out x Off (where x is 1 through 16)
OUTxTOG Aux Out x Toggle (where x is 1 through 16)
DP1ON Digital 1 Power On
DP1OFF Digital 1 Power Off
DV1ON Digital 1 Video On
DV1OFF Digital 1 Video Off
DP2ON Digital 2 Power On
DP2OFF Digital 2 Power Off
DV2ON Digital 2 Video On
DV2OFF Digital 2 Video Off
SPROJON Slide Projector On
SPROJOFF Slide Projector Off
yn, Request a response flag.
Y The eCNA will respond with it’s response message
N This eCNA will not respond.
checksum Checksum (0 to 65535). Unsigned 16-bit decimal sum of all preceding characters or wildcard ‘??’
<CR> Terminating carriage return. (ASCII control character, 0x0D)
<LF> Terminating line feed. (ASCII control character, 0x0A)
